2018 Call for Projects Application List

Who is Completing the Application?

Please provide contact information for the person who will complete the online application for this project. The email address and password entered here will be used to complete and submit both Pre-Applications and Applications.

Primary Agency Information

Please provide contact information for the agency official who is representing the project sponsor. This individual will be considered the official applicant and must be authorized by their agency to submit this request for funding and make necessary assertations and representations on the agency’s behalf.

Additional Agency Information

1. Is this project being developed and/or implemented in partnership with another agency?

Project Information

1. Project Title

Aldine Westfield Road

2. Project County

Harris County

3. Facility/Street Name

Aldine Westfield

4. Project limits (from, to) or location (Address)

Beltway 8 to Little York Rd

5. Describe the primary problems to be addressed by the project (Project Need).

Aldine Westfield is a 7.6 mile 2-lane open ditch roadway that connects residents to Bush Intercontinental Airport (IAH) and the Greenspoint office area. The pavement along the corridor is in poor condition and has insufficient capacity for projected ADT. Current traffic flow at peak periods is severely congested, especially at intersections due to the lack of turn lanes. LOS for current volunes at intersections are D to F, with projections showing LOS of F. Safety challenges include limited sidewalks along the corridor and no ADA compliant cross ramps. The intersections on this corridor do not have dedicated turn lanes and the signals are on span wire. Aldine Westfield north of Beltway 8 is designated as a freight corridor.

6. Describe the proposed improvement/activity (Description).

The proposed project would improve the roadway to a 4-lane corridor with improved intersections and turning lanes, upgraded signals, and pedestrian facilities. The roadway will also act as resilient project providing the north-south connection between I-45 and US59 during various emergency events. Improvement to the roadway will allow for pedestrian improvements to access nearby Keith Wiess Park, Squatty Lyons Park, Aldine Middle School, YES Prep, and TS Grantham Middle School. Drainage for the corridor will also be improved with a storm sewer system and off-site detention in partnership with Harris County Flood Control District. See attached map and document (pg 7 of pdf)

7. Describe the primary outcomes to be achieved by the project (Project Purpose)

Improved LOS and Intersection Operation with the additional lane capacity, medians, and turn lanes. Improved pedestrian safety and accessibility with new 6ft sidewalks and ADA compliant ramps/crosswalks. The roadway will be reconstructed, providing a new concrete roadway and extending its service life. Currently a transit corridor does not exist, but with the improvement of the roadway and pedestrian realm, access to community centers, parks, and schools may drive the needs for new transit connections. The adjacent land uses along the corridor are still primarily low-density but location is likely to foster economic development and increased density. Improvements to the underground utilities and storm drainage to convey design and extreme events will also enhance the roadway.

8. Have any MPOID numbers been assigned to this project?

No

9. Have any TxDOT Control-Section-Job (CSJ) numbers been assigned to this project?

No

10. What is the estimated total capital investment required for the project?

Less than $100 million

A. Investment Category & Strategy

(Expand) Roadway Added Capacity/New Construction/Complete Streets

11. Please provide the federal funding amount requested.

52063502

12. Please upload the funding commitment letter or letters of support from the local government.

HPW PreAp letter.pdf

Project Development/Readiness

1. Please select the level of engineering completed.

Not Started

2. What is the completed or anticipated level of environmental documentation required for the proposed project?

Environmental Assessment (EA)

A. What was/is the anticipated completion date of the environmental clearance?

12/16/2022

3. Will any of the following be required to implement the project? US Army Corps of Engineers Permits

No

US Coast Guard Permits

No

Railroad Agreements

No

None of the Above

Yes

4. Will the acquisition of Right of Way or an easement be required to implement the project?

Yes

A. What was/is the estimated completion date for Right of Way/easement mapping?

01/21/2022

B. What was/is the estimated start date for Right of Way/easement acquisition?

02/18/2021

C. What was/is the estimated completion date for Right of Way/easement acquisition?

02/17/2023

D. How many parcels must be acquired to implement the project?

n/a

E. How many parcels have been acquired to date?

n/a

5. Has utility coordination been initiated for the project?

No

6. Will the project improve or significantly affect infrastructure owned or operated by another agency?

No

8. Please provide any additional project development/readiness information relevant to the proposed project. (6000 characters max) (Optional)

The City conducted a pre-engineering study for this corridor. Attached report of the results/analysis. Also attached is HCFCD Bond list for drainage improvement on the Halls Bayou channel; specifically on P-118-00-00 (see pg 6-7)

9. Additional Project Development/Readiness Attachment (Optional)

Aldine Westfield Report_SupportLetter.zip

Map/Location

1. Please provide a clear and concise GIS coverage or PDF map for the proposed project. (MPK ESRI Map Package file preferred)

Aldine Westfield_map.pdf

Project Budget

1. Please attach a completed project budget worksheet. Templates are available on the 2018 Call for projects website.

project-budget-AldineWestfield.xlsx

2. Are Transportation Development Credits (TDCs) being requested?

No

Benefit/Cost Analysis

1. Safety Benefits

Roadway-Safety-Benefits-AldineWestfield.xlsx

2. Delay Benefits

10302018111729AM.xlsx

3. Emissions Benefits

Roadway-Emissions-Benefits-AldineWestfield.xlsx

4. Additional BCA Documentation (Optional)


5. Additional BCA Documentation (Optional)

Aldine_map_resolution.zip

6. Please provide a brief narrative describing the methodology, input data and results. (Optional)

Aldine Westfield is being submitted under the added capacity/complete street category. The proposed project was study under a pre-engineering effort that looked at the corridor from Little York to Beltway 8. Using current traffic counts and projected traffic model data, a 4-lane boulevard section was recommended. The proposed project includes raised medians, safety lighting, intersection lighting, pedestrian crosswalks, upgraded signals and intersection turn-lanes. Recent Harris County Flood Control District bond election approved channel work and detention improvements along the Halls Bayou (P-118-00-00) system. This drainage system and the proposed plan for Aldine Westfield are being coordinated to address regional drainage in the area.

Planning Factors - Connectivity to Employment/Eliminates At-Grade Railroad Crossings

1. Does the facility directly connect to or is located within 1/2 mile of employment?

Yes

A. If yes, please indicate number of jobs the facility directly connects to or is within a 1/2 mile?

901 - 1000

2. Does the proposed project eliminate or prevent at grade railroad crossing?

No

Planning Factors - Environmental Justice

1. Is the proposed project located in or is adjoining an environmental justice sensitive area (census block groups) identified by HGAC?

Yes

A. If Yes, Will the project incorporate measures that reduce, minimize or avoid adverse effects environmental justice sensitive areas (census block groups) identified by HGAC?

Yes

Planning Factors - Improves Corridor Level of Travel Time Reliability (LOTTR)

1. The proposed project will reduce Planning Time Index (PTI) by:

0.11 - 0.20

2. Please upload your completed LOTTR template.

lottr-estimation-template Aldine Westfield.xlsx

Planning Factors - Improves Multimodal LOS

1. Does the proposed project improve highway/freight LOS?

Yes

2. Does the proposed project improve transit LOS?

Yes

3. Does the proposed project improve bike/pedestrian LOS?

Yes

4. Please provide a brief narrative explaining how proposed project improves multimodal LOS (Auto, Bike/Ped, and Transit).

Currently Aldine Westfield is a two-lane open ditch roadway with no sidewalks, no ADA ramps, or safe crosswalks. The proposed improvement will provide for continuous sidewalks on both sides of the street, with intersection improvements that include ADA crosswalks and ramps. Though Aldine Westfield is not designated on the freight network, it is designated from Beltway 8 north. The proposed improvement will improved and provide that connection between Hardy Toll Road and US 59. It will also provide connections to existing local freight corridors, Aldine Bender and Ley Road, that intersect Aldine Westfield.

Planning Factors - Planning Coordination

1. Is the proposed project recommended in a regional/sub regional/or locally adopted plan including regional thoroughfare plans? Or Has the sponsor conducted interagency coordination with other local or state agency affected by the proposed project?

Yes

A. If yes, please provide the title of the regional/sub regional or local plan in which the proposed project is recommended.

City of Houston Major Thoroughfare and Freeway Plan

B. If yes, please provide a link to the regional/sub regional or local plan in which the proposed project is recommended.

https://www.houstontx.gov/planning/transportation/MTFP.html

Planning Factors - Roadway Hierarchy/Freight System Priority/Evacuation Route

1. Please select the functional classification of the roadway on which the proposed project is located, based on the characteristics of the roadway after the project is implemented. The FHWA Highway Functional Classification Concepts, Criteria and Procedures is provided in the link below.

Collector

2. Is your project located on one of the following? Greater Houston Freight System

No

Locally Designated Freight Corridor

No

State Designated Evacuation Route

No

None of the Above

Yes
